P357 Pneumatic Powered Plastic Strapping Tool

The new FROMM P357 is an excellent all-round industrial strapping tool. Its well-balanced construction and ergonomically positioned control buttons allow for one hand operation and all kinds of vertical and horizontal strapping applications.

The P357 is best suited to high volume strapping environments, as it operates continuously without the need to be recharged. Due to its robust and durable design it is the perfect addition to any industrial warehouse or factory. Compatible with both PP & PET strapping and tensioning of up to 2500N.





Strap Width 12.7 16 Tension 2500 friction-weld.jpg air.jpg
star-icon.gif Advantages & Benefits
  • Single hand operation tool;
  • Select the operation mode that best fits to your job: manual (2-buttons) or semi-automatic (1-button);
  • Easy strap threading – both straps are inserted together;
  • Strap tension can be set and blocked for correct and consistent secured packages;
  • Seal time is easy to adjust, to get the best possible seal efficiency;
  • To warrant an optimal seal cooling time, the signalisation pin shows you the end of each strapping cycle;
  • Pneumatically powered, very reliable and maintenance-friendly;
  • This tool is ideal for a wide variety of vertical and horizontal strapping positions, suitable for almost all applications in various industries.
  • The perfect solution in case electrical powered tools, for safety or technical reasons, must not or cannot be used;
  • The compressed air, can be connected to the tool either on top of the main housing or at the rear end;
  • For packages with a rough and hard surface, a bottom-base wearing plate is available as accessory;
  • In cases where soft packages are to be strapped, a plastic bottom-base protection plate is available;

Technical Specifications

  • Strapping qualities Polyester (PET) and Polypropylene (PP), plain and embossed
  • Strapping dimensions width 12,7 – 16,0 mm / 1/2 – 5/8”
    thickness 0,40 – 1,05 mm / .016 – .041”
  • Weight 5,7 kg / 12.6 lbs
  • Tool size L350 x W133 x H135 mm / 13.8” x 5.2” x 5.3”
  • Type of seal Sealless, Friction weld sealing
  • Average seal strength approx. 75% (depending on strap quality)
  • Tension force: 600 – 1.300 N / 135 - 292 lbs | 1.200 – 2.500 N / 270 – 562 lbs, adjustable
  • Max. air pressure 5,5 - 6.0 bar / 80 - 87 psi
  • Air consumption 60 Nl/min – 2.1 cu.ft/min Max. pressure drop of 0,5 bar / 7.25 psi
  • Suspension bracket supplied with the tool
